Copper Patch Cord Fiber Optic Patch Cord

MTP/MPO (LX4052)

CreateDate:2017-01-11  Hits:

Product Description:

LASUN MTP/MPO trunk cable components refer to the two ends of the cable are using multi- MPO/MTP Connectors which comply to the Telcordia-GR-326, IEC standard and ROHS requirements,

Conducive to the rapid deployment of optical fiber infrastructure and data center environment, Crossing between MDA,HAD andEDA regional moduleor fanout fiber optic cableconnections,high Performance Plug-and-play architecture effectively reduces the installation and ongoing maintenance costs.Widely used in enterprise’ local area network cabling between different buildings, Base station cabling,

residential, Business building room light connection, intensive building cabling systems, local area networks (LANs) and WANS FTTX fiber to households.

Product Features

1,High quality ferrules, precise alignment PIN ,male(with Pin),female(without Pin);

2,Smooth upgrade from 10G to 40G, 100G networks, and supports the 100G transmission delay index;

3,Low insertion loss, complete the connection in the factory, and a full set of stringent testing ;

4,Optional main cable structure of 12-144 core multi core cables,  per 12 increment cores;    Optical fiber core cable increasing by every 12 cores.

5,Using a small round diameter structure, achieved smaller backbone cable bending radius ,

 allows storage and easy laying quickly, minimizing failure and reduced cabling space.

6,SM G652D,G657A fibers and MM OM3, OM4 for choice;

7, MPO/MTP optional connectors, pre-connect design, easy to install,  short duration;

8, Good interchangeability and mutual plug;

9, In accordance with customer needs, customized length of cable;

10, Unique compression, tensile strength, water blocking,which effectively protect the optical fiber

cable and optical fiber connectors are not damaged during transportation and

installation, ensure that the use of process quality and stability.

11,LSZH ,PVC for choice.
