2-4Cores Telephone Cable (LX1021)

CreateDate:2017-01-10  Hits:
    • LASUN
    • Iso9001ISO9001
    • ULUL
    • FTPUTP
    • CAT6CAT3

Product DescriptionUTP Cat3
Rated temperature 60,75,90
Reference Standard UL444,UL1581 ,UL1666
Bare solid copper conductor
Rohs/REACH complied PVC Jacket
Flame Test: CMX,CM,CMR
Installation temperature -30℃~+50

Application:

10 Base

100 Base-T4

Voice and Telephone wiring





Data Sheet

General

U/UTP Cat 3 1-2P



Test

Standard

ISO/IEC11801, TIA-568-C.2

Conductor

Material

Solid-Bare Copper

O.D(mm)

0.50±0.008

Insulation

Material

HDPE

O.D(mm)

0.91±0.05

Pairs

1

White-Orange/Orange

2

Blue/Yellow

Sheath Physical Properties

Tensile before aging(MPA)13.5

      Elongation(%)  150

Aging Period(*hrs) 100*24h*7d



Seperator



Material



/

Tensile after aging(MPA)12.5

      Elongation(%)  125

Cold Bend(-20±2*4hrs)

 Rip Cord

Material

/

Electrical Characteristics

1-16MHZ

Impedance   100±15Ω

Delay Shew(ns/100m)  45

Sheath

Thickness

0.60±0.05 mm

NVP     69%

Outer O.D

4.2±0.2mm

Surface

Half a mist side

Capacitance(NF/100M) Max   5.6

Material

PVC or LSZH

DC Resistance(Ω/100M)Max    9.5

Color

Depend on your requirement

DC Resistance Unbalance 5%

Packing

Carton Package

Wooden Dimension

Inner: 360*360*215mm  Outer:385*380*465mm

Packing Length

Standard 305± 1.5m
