Industry Standard:

1.UL, C(UL)listed

2. Meets FCC parts 68

3. ANS/TIA/EIA-568B

4.ISO/IEC 11801

5. ETL verified EIA/TIA T568B

6.Transmission performance

Physicals:

1. IDC connector accept 22-26 AWG solid wire

2. Jack wiring:30-micron inch gold plate over 100 -micron inch nickel

3.Housing: High impact flame retardant plastic UL94V-0 rated

4. IDC connector suitable for 110 punch down and Krone tool

5. Mateial: PC

Mechanical:

1. Plug insertion life: 750 cycle min

2. Plug retention force: 30 lbs min

Electrical:

1. Current rating: 1.5Amps

2. Insulation resistance: 500Mega-ohms min

3. Contact resistance: 20 Milli-ohms max

4. DC resistance: 0.1 ohms max

5. Data transmission rates up to 250Mbps
